500 W magneto• X-package coloration, graphics and seat cover
Specifications
Type
48 hp, Rotax 570 cc V-twin, snorkeled, liquid cooled with relocated radiator
Fuel Delivery System
Electronic Fuel Injection (EFI)
Transmission
CVT, P/R/N/H/L, standard engine braking
Drive Train
Selectable 2WD/4WD with Visco-Lok QE auto-locking front differential
Power Steering
Tri-Mode Dynamic Power Steering (DPS)
Front Suspension
Double A-arm
Front Shocks
Oil
Rear Suspension
Torsional Trailing-Arm Independent (TTI)
Rear Shocks
Oil
Front Tires
ITP Mega Mayhem 28 x 8 x 12 in. (71.1 x 20.3 x 30.5 cm)
Rear Tires
ITP Mega Mayhem 28 x 10 x 12 in. (71.1 x 25.4 x 30.5 cm)
Wheels
12 in. cast-aluminum
Front
Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear
Single 214 mm ventilated disc brake with hydraulic twin-piston caliper
Fuel Capacity
5.4 gal (20.5 L)
L x W x H
83 x 46 x 49 in. (211 x 116.8 x 124 cm)
Wheelbase
51 in. (129.5 cm)
Ground Clearance
11.7 in. (29.7 cm)
Seat Height
33.8 in. (85.8 cm)
Rack Capacity
Rear: 240 lb (109 kg)
Storage Capacity
Rear: 2.9 gal (10.9 L)
Towing Capacity
1,300 lb (590 kg)
Estimated Dry Weight
843 lb (382 kg)
Gauge
4.5 in. digital display: Speedometer, tachometer, odometer, trip and hour meters, gear position, 4 x 4 indicator, temperature, engine lights, electronic fuel gauge and clock
Instrumentation
Lighter type DC outlet in console, standard connector in the back (15 A)
